| CPU | Intel® Socket 2066 Core™ X-Series Processors Optimized for Intel® Core™ X-Series 10000 Processor Family Supports Intel® Virtual RAID on CPU (VROC) Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Max Technology 3.0 |
| Chipset | Intel® X299 |
| Memory | Intel® Core™ X-series Processors (6-core above) 8 x DIMM, Max. 128GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). * Hyper DIMM support is subject to the physical characteristics of inpidual CPUs. |
| Multi-GPU Support | Supports NVIDIA® 3-Way SLI™ Technology Supports NVIDIA® 2-Way SLI™ Technology Supports AMD 3-Way CrossFireX™ Technology Supports AMD 2-Way CrossFireX Technology |
| Expansion Slots |
|
| Storage | Intel® Core™ X-Series Processors Family : 1 x ROG DIMM.2 Module supports 2 M.2 Socket 3 , with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*4 Intel® Rapid Storage Technology Enterprise supports Intel® X299 Chipset : 1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) 1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*5 8 x SATA 6Gb/s port(s) Support Raid 0, 1, 5, 10 Intel® Rapid Storage Technology supports Intel® Optane™ Memory Ready |
| LAN | Aquantia AQC-107 10G Intel® I219V Anti-surge LANGuard ROG GameFirst Technology |
| Wireless Data Network | Intel® Wi-Fi 6 AX200 Supports channel bandwidth: HT20/HT40/HT80/HT160 2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz Up to 2.4Gbps transfer speed |
| Bluetooth | Bluetooth® 5.0 |
| Audio | ROG SupremeFX 8-Channel High Definition Audio CODEC S1220 - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - SupremeFX Shielding Technology - ESS®SABRE9018Q2C DAC/AMP - Supports up to 32-Bit/192kHz playback *6 Audio Feature : - DTS® Sound Unbound - Optical S/PDIF out port(s) at back panel - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path. - Sonic Radar III - Sonic Studio III + Sonic Studio Virtual Mixer |
| USB Ports | Rear USB Port 1 x USB 3.2 Gen 2x2 (up to 20Gbps) port(s) (1 x Type-C) 2 x USB 3.2 Gen 2 (up to 10Gbps) port(s) (1 x Type-A + USB Type-CTM) 8 x USB 3.2 Gen 1 (up to 5Gbps) port(s) (8 x Type-A) 1 x USB 2.0 port(s) (1 x Type-A) Front USB Port 2 x USB 3.2 Gen 2 (up to 10Gbps) port(s) 4 x USB 3.2 Gen 1 (up to 5Gbps) port(s) 2 x USB 2.0 port(s)) |
| ROG Exclusive Features | Clear CMOS button Extreme Engine Digi+ : - MicroFine Alloy Chokes - 10K Black Metallic Capacitors ROG Extreme OC kit : - OptiMem III - ReTry button - Safe Boot button - Start button - Slow Mode - LN2 Mode - EZ Plug - FlexKey Button ProbeIt ROG Exclusive Software - Mem Tweakit - RAMCache III - RAMDisk - CPU-Z - GameFirst V - Sonic Radar III - Overwolf - Sonic Studio III + Sonic Studio Virtual Mixer ROG DIMM.2 module with heatsink ROG Aluminum heatsink cover |
| Special Features | ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 : - 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo Core App AI Overclocking LiveDash OLED 1.77 ” AURA : - Aura Lighting Control - Aura RGB Strip Headers - Aura Lighting Effects Synchronization with compatible ASUS ROG devices - Addressable Gen 2 Header ASUS Exclusive Features : - USB BIOS FlashBack™ - AI Suite 3 - Ai Charger - ASUS CrashFree BIOS 3 - Armoury Crate - Pre-mounted I/O Shield - ASUS NODE: hardware control interface - ASUS C.P.R.(CPU Parameter Recall) ASUS Q-Design : - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector Armoury Crate |
| Back I/O Ports | 1 x USB 3.2 Gen 2x2 (up to 20Gbps) ports (Type-C) 1 x USB 2.0 1 x Optical S/PDIF out 1 x Clear CMOS button(s) 1 x USB BIOS FlashBack™ Button(s) 1 x ASUS Wi-Fi Module 5 x LED-illuminated audio jacks 8 x USB 3.2 Gen 1 (up to 5Gbps) ports 2 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A + USB Type-CTM) 1 x Aquantia AQC-107 10G LAN port Anti-surge LAN (RJ45) port |
| Internal I/O Ports | 1 x W_PUMP+ 1 1 x W_PUMP+ 2 1 x WB_SENSOR 2 x Aura Addressable Strip Header(s) 2 x Aura RGB Strip Headers 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) 8 x SATA 6Gb/s connector(s) 1 x VROC_HW_Key 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x H_AMP fan connector 1 x HS_FAN 1 x 24-pin EATX Power connector(s) 2 x 8-pin EATX 12V Power connectors 1 x 6-pin EZ_PLUG Power connector(s) 1 x 4-pin EZ_PLUG Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Slow Mode switch(es) 10 x ProbeIt Measurement Points 1 x BIOS Switch button(s) 1 x Node Connector(s) 1 x LN2 Mode jumper(s) 1 x Safe Boot button 1 x ReTry button 1 x System panel connector 2 x T_Sensor Connector 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header 1 x Start button 2 x USB 3.2 Gen 2 front panel connector 1 x Speaker connector 1 x DIMM.2 Slot supports 2 M.2 drives (2242-22110) 1 x PAUSE Switch 1 x RSVD Switch 1 x FlexKey button 1 x FS Mode switch |
| Accessories | User's manual 1 x ROG logo plate sticker 6 x SATA 6Gb/s cable(s) 3 x M.2 Screw Package 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x Fan Extension Card II (6 x 4-pin Chassis Fan connectors, 3 x RGB headers, 3 x 2-pin Thermal sensor header) 1 x Fan Extension Card II power cable 1 x Fan Extension Card II NODE connector cable 1 x Fan Extension Card II screw package 1 x Q-Connector 1 x ROG Logo Sticker(s) 1 x Extension Cable for RGB strips (80 cm) 1 x Extension cable for Addressable LED 3 x Thermistor cable(s) 1 x USB drive with utilities and drivers 1 x ROG coaster(s) 1 x USB 3.2 Gen 1 Header to USB 2.0 adapter cable 1 x ROG weave SATA 6G cable 1 x ROG DIMM.2 with heatsink 1 x M.2 Pad for ROG DIMM.2 1 x 2-in-1 Rubber pad 1 x ROG Multi-Bit screwdriver |
| BIOS | 2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0 |
| Manageability | WfM 2.0, WOL by PME, PXE |
| Support Disc | Overwolf Daemon Tools Software WinRAR Anti-virus software (1-year full subscription) |
| Form Factor | Extended ATX Form Factor 12 inch x 10.9 inch ( 30.5 cm x 27.7 cm ) |
