Basic

Dimensions ( W×D×H )

128 mm x 102 mm x 60 mm (5.04 in. × 4.02 in. × 2.36 in. antennas not included)

Weight

0.25 kg (packages not included)

Wi-Fi Standards

Wi-Fi 5 (802.11ac)

MIMO

2.4 GHz, 2×2, MU-MIMO 5 GHz, 2×2, MU-MIMO

Max. Wi-Fi Speed

2.4 GHz: 300 Mbps 5 GHz: 867 Mbps

Channel Width

2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80 MHz

Antennas

2

Antennas Type

External Omnidirectional

Antenna Gain

2.4 GHz: 4 dBi 5 GHz: 4 dBi

Port

1×10/100 Base-T WAN/LAN

Recommended Users

24

Max. Users

96

Power Supply

100-240V~50/60Hz 0.5A

Power Consumption

≤15W

Operation Frequency Bands

802.11b/g/n/: 2.400 GHz to 2.483 GHz 802.11a/n/ac: 5.150 GHz to 5.350 GHz 802.11a/n/ac: 5.470 GHz to 5.725 GHz , 5.725 GHz to 5.850 GHz  country-specific restrictions apply

Transmit Power

Regular: CE EIRP: ≤20dBm (2.4GHz) ≤27dBm (5GHz) ≤20dBm 2400~2483.5MHz(Bluetooth) Myanmar: 2400~2483.5MHz ≤ 20dBm(EIRP) ; 5150~5350MHz ≤ 23dBm(EIRP) ; 5470~5725MHz ≤ 30dBm(EIRP) ; 5725~5850MHz ≤ 30dBm(EIRP) ;

Operating Temperature

-10 °C to +45 °C (14 °F to 113 °F)

Operating Humidity

5% to 95% Noncondensing

Certifications

CE,RoHS
