Technical Specifications

General

Operating Modes

+ Access Point (AP)
+ WDS with AP
+ WDS/Bridge (No AP Broadcast)
+ Wireless Client

LED

+ Power
+ 5GHz
+ LAN
+ 2.4GHz

Standards

+ IEEE 802.11n
+ IEEE 802.11a
+ IEEE 802.11g
+ IEEE 802.3ab
+ IEEE 802.3af
+ IEEE 802.3u
+ IEEE 802.3

Wireless Frequency Range

+ 2.4GHz (2.4GHz to 2.4835GHz)
+ 5GHz (5.15GHz to 5.35GHz, 5.47GHz to 5.85GHz

Antennas

+ Four internal 3 dBi for 2.4 GHz

Functionality

Security

+ WPA™-Personal
+ WPATM-Enterprise
+ WPA2™-Personal
+ WPA2TM-Enterprise
+ 64/128-bit WEP
+ SSID Broadcast Disable
+ MAC Address Access Control
+ Network Access Protection
+ Internal RADIUS Server

Network Management

+ Command Line Interface
  - Telnet
  - Secure (SSH) Telnet
+ Web Browser interface
  - HTTP
  - Secure HTTP (HTTPS)
+ SNMP Support
  - D-View Module
  - Private MIB
+ AP Manager II
+ AP Array
+ Traffic Control
