Size (L x W x H) | • 14.5 x 12.25 x 2.5 in
• (36.8 x 31.1 x 6.4 cm) |
Weight | • 1.75 lb. (0.8 kg) |
Power | • 110V 60Hz AC / 220V 50 Hz AC (depending on country-specific SKU) |
Network interface | • Two-wire RJ-11 analog PBX or public switched telephone network interface |
Display* | • 132×65 pixel backlit graphical LCD |
User interface* | • User selectable ring tones
• Configurable soft keys for easy dialing of voice conferencing services
• Multi-lingual support: English, German, French, Italian, Spanish, Portuguese, Norwegian
• Password protected configuration settings for administrators |
Caller ID and phone book* | • Support for multiple Caller ID standards**:
+ Bellcore Type 1 (requires a telephone company subscription for activation)
+ ETSI
+ DTMF
+ British Telecom
• Phone book/speed dial list – up to 25 entries* |
Keypad | • 12-key telephone keypad
• On-hook/off-hook, conference, mute, volume up/down keys, menu, navigation keys*
• 3 context sensitive soft keys* including redial, hold, programmable conference key |
Console loudspeaker | • Frequency response: 300 to 3300 Hz
• Volume: adjustable to 94 dBA SPL (peak) volume at 0.5 meters |
Console microphones | • 3 cardioid microphones 300 to 3500 Hz |
Audio | • Polycom Acoustic Clarity full duplex – IEEE 1329
• Type 1
• Up to 10 ft. microphone pick-up range
• Gated microphones with intelligent microphone mixing
• Dynamic noise reduction |
Interfaces | • 2 EX microphone connections*
• Applications Port* for connection to other communication devices such as mobile phones† and computers
• RCA Auxiliary audio jack |
Accessories | • 2 cardioid extension microphones 300 – 3500 Hz (for EX model only) |
Regulatory compliance | • NA Cl/C-UL
• FCC Part 68
• FCC Part 15 Class B
• Canadian ICES-003
• CE Mark (R & TTE Directive)
• VCCI Class B (Japan) |
Environmental requirements | • Operating temperature: 40° – 104°F (5° – 40°C)
• Relative humidity: 20% – 85% (noncondensing)
• Storage temperature: -22° – 131°F (-30° – 55°C) |
Recommended room conditions | • Reverberation time: <0.5 seconds
• Noise level: <48 dBa |
SoundStation2 ships with: | • Tabletop phone console
• 21 ft. (6.4 m) cord to console
• 7 ft. (2.1 m) telco cable to RJ-11 telephone jack
• User documentation (user guide CD, quick installation guide, registration card) |
Warranty | • 1 year |
Part Numbers (North America) | • 2200-15100-001: SoundStation2, non-expandable
• 2200-16000-001: SoundStation2, non-expandable, with display
• 2200-16200-001: SoundStation2, expandable, with display
• 2200-16155-001: Extension microphone kit |
