SPUN COPPER IMG WOOFER
Injection Molded Graphite (IMG) woofers are exceptionally light while
being extremely rigid – providing remarkable low frequency response, with
minimal cone breakup and distortion.
WIRELESS HIGH FIDELITY CONNECTIVITY
2.4GHz connectivity allows for premium, CD-quality sound anywhere in the
room. Simply connect the compact, pre-paired transmitter to the subwoofer
or LFE out on your receiver.
ALL-DIGITAL AMPLIFIER
The built-in all-digital amplifier delivers ample power with high efficiency
and true-to-source accuracy in reproduction.
FRONT-FIRING DRIVER
The high performance driver provides deep bass and placement flexibility.
LOW PASS CROSSOVER AND PHASE CONTROL
Allows you to blend the subwoofer’s low-frequency tones with other Klipsch
speakers as well as establish the ideal level of bass.
LINE/LFE INPUTS
Ensures compatibility with old and new receivers.
MDF CABINETS WITH BRUSHED POLYMER VENEER FINISH
Contemporary aesthetic with absolute durability that results in a seamless
integration into any décor.
FRONT-MOUNTED LED POWER INDICATOR
Let’s you know when the system is on or off.
STRONG, FLEXIBLE, REMOVABLE GRILLE
Adds a rich, refined look that is acoustically transparent.
FREQUENCY RESPONSE 29Hz-120Hz +/-3dB
MAXIMUM ACOUSTIC OUTPUT 116dB
AMPLIFIER All digital
AMPLIFIER POWER 200W / 400W
DRIVE COMPONENTS 12" (30.5 cm) high excursion, IMG, front-firing woofer
ENCLOSURE MATERIAL MDF
ENCLOSURE TYPE Bass Reflex via rear-firing tube port
INPUTS 2.4GHz CD-quality wireless; Line level/LFE RCA jacks
HEIGHT 16" / 40.64 cm (16.5" with feet)
WIDTH 14" / 35.56 cm
DEPTH 18.5" / 47 cm (19.2" with grille)
WEIGHT 33 lbs (15 kg)
FINISH Brushed Black Polymer Veneer
BUILT FROM 2014
FEATURES Volume, Lowpass, Phase, Auto Power
PHASE Switchable 0-180 degrees
POWER CORD Detachable
PART NUMBERS CE (230V): 1063516
