Mainboard AAEON MIX-Q370A1-A11-4L

PROCESSOR

8th/9th Gen. Intel® Core™ LGA 1151 socket Processor (formerly Coffee Lake-S), Max. 65W TDPs

CHIPSET

Intel® Q370 Express Chipset

MEMORY

DDR4 2666/2400/2133 MHz SODIMM x 2, Up to 32GB, Non-ECC,
Un-buffered Memory, Dual channel memory architecture

I/O CHIPSET

NCT6793D

LAN

GbE x 4

AUDIO

Realtek® ALC887 with Amp.

EXPANSION SLOT

PCIe3.0 [x16] x 1, M.2 E-key(22x30mm; Support CNVi)

BIOS

256Mbit Flash ROM, AMI BIOS

H/W MONITOR

Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/12V, Fan Monitor on CPU/Chassis

WATCHDOG TIMER

1~255 steps by software program

SMART FAN CONTROL

CPU Fan/ Chassis Fan

WAKE ON LAN/ PXE

Yes (WOL / PXE)

POWER STATE

S3, S4, S5
