| SYSTEM | |
| FORM FACTOR | Pico-ITX |
| CPU | J6412 (4C/4T, 2.00GHz, 10W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | Onboard LPDDR4x 3200, Single Channel, Non-ECC (Default: 4GB) |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | Intel® PTT (Integrated TPM) |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION | 3.94" x 2.84" (100mm x 72mm) |
| GROSS WEIGHT | 0.18 lbs (0.08 kg) |
| OS SUPPORT | Windows 10 (64 bit) Ubuntu 20.04.4/Kernel 5.13.0-30-generic |
| POWER | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | AT/ATX |
| CONNECTOR | Phoenix 2-pin Connector (Default) Lockable DC Jack Connector (colay) |
| POWER CONSUMPTION | Intel® Atom™ x6425E, LPDDR4x onboard 16GB, 2.48A@ +12V(TYPICAL) Intel® Atom™ x6425E, LPDDR4x onboard 16GB, 2.62A@ +12V(MAX) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1 (18/24bit 2CH) 1920 x 1200 @60Hz |
| DISPLAY INTERFACE | HDMI 2.0 x 2, 3840 x 2160 @60Hz |
| MULTIPLE DISPLAY | Up to 3 Simultaneous Displays |
| EXTERNAL I/O | |
| ETHERNET | Realtek 8111 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen2 x 2 |
| VIDEO | HDMI 2.0 x 2 |
| INTERNAL I/O | |
| USB | USB2.0 x 2 |
| SERIAL PORT | COM1~2 (RS232/422/485, support 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1, +5V SATA Power Connector x 1 eMMC5.1 32GB |
| DIO/GPIO | GPIO 4-bit |
| SMBUS/I2C | I2C/SMBus x1 (Default: SMBus) |
| FAN | 4pins Smart Fan x1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| MINI PCI-E/MSATA | Full size mPCIe/mSATA x 1 (SATA as default, PCIe selected by BIOS) |
| M.2 | M.2 2230 E-Key x 1 (PCIe 3.0 [x1] + USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | 32°F ~ 140°F (0°C ~ 60°C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 489,989 |
| EMC | CE/FCC Class A |
