| SYSTEM | |
| FORM FACTOR | PICO-ITX |
| CPU | Intel® Core™ Ultra 5 Processor 125U (2PC+10EC/14T, P-core 1.30 GHz, E-core 0.80 GHz, 15W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | Single-Channel LPDDR5 6400, default with 16GB |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| Security | TPM 2.0 |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 3.94" x 2.84" (100mm x 72mm) |
| Gross Weight | 0.18 lbs. (0.08 kg) |
| OS Support | Windows 10 (64bit) Linux Ubuntu 22.04.2 kernel 5.19.0 32 generic |
| POWER | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | AT/ATX |
| CONNECTOR | Phoenix 2-pin Connector (Default) Lockable DC Jack Connector (colay) |
| POWER CONSUMPTION | Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 2.94A@+12V (Typical) Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 5.13A@+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® Graphics |
| LVDS/eDP | eDP 1.4 x 1 |
| Display Interface | HDMI 1.4 x 1, 3840 x 2160 @30Hz |
| Multiple Display | Up to 2 Simultaneous Displays |
| AUDIO | |
| CODEC | — |
| AUDIO INTERFACE | — |
| EXTERNAL I/O | |
| ETHERNET | Intel® Ethernet Controller I226 2.5GbE, RJ-45 x 1 Intel® Ethernet Connection I219, 1GbE, RJ-45 x 1 |
| USB | USB 3.2 Gen 2 x 2 ports |
| VIDEO | HDMI 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 2 |
| SERIAL PORT | COM 1 ~ 2 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | — |
| SATA | SATA 6Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | — |
| DIO/GPIO | GPIO 4-bit |
| SMBus/I2C | I2C/SMBus (Default: SMBus) |
| FAN | 4pins Smart Fan x1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| MINI PCI-E/MSATA | — |
| M.2 | M.2 2280 M-Key x 1 (PCIe 4.0 [x4] / SATA, Default: PCIe [x4], select by BOM) M.2 2230 E-Key x 1 (PCIe 4.0 [x1] + USB 2.0) |
| Others | — |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | -4°F ~ 158°F (-20°C ~ 70°C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 1,063,716 |
| EMC | CE/FCC Class A |
