| SYSTEM | |
| FORM FACTOR | PICO-ITX |
| CPU | Intel® Core™ i7 1370PE (6P+8E/20T, 1.90 GHz, 28W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | DDR5 5200, SODIMM x 1, Non-ECC (Max. 32GB) |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | TPM 2.0 |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 3.94" x 2.84" (100mm x 72mm) |
| Gross Weight | 0.18 lbs. (0.08 kg) |
| OS Support | Windows 10 (64bit) Ubuntu 22.04.2 (eDP is verified on Ubuntu 23.10.1) |
| POWER | |
| POWER REQUIREMENT | 12V only |
| POWER SUPPLY TYPE | AT/ATX |
| CONNECTOR | Phoenix 2-pin Connector (Default) Lockable DC Jack Connector (colay) |
| POWER CONSUMPTION | Intel® Core™ i7-1370PE, DDR5 32GB, 4.51A@ +12V (TYPICAL) Intel® Core™ i7-1370PE, DDR5 32GB, 7.46A@ +12V (MAX) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics |
| LVDS/eDP | LVDS x 1 (18/24bit 2CH) 1920 x 1200 @60Hz eDP 1.4 x 1, up to 3840 x 2160 (Optional) |
| Display Interface | HDMI 1.4 x 1, 3840 x 2160 @30Hz |
| Multiple Display | Up to 2 Simultaneous Displays |
| AUDIO | |
| CODEC | Realtek ALC256 |
| AUDIO INTERFACE | Line-in/Line-out/Mic (Optional, Audio function not available for WiTAS SKU) |
| EXTERNAL I/O | |
| ETHERNET | Intel® i226 2.5GbE, RJ-45 x 1 Intel® i219, 1GbE, RJ-45 x 1 |
| USB | USB 3.2 Gen2 x 2 |
| VIDEO | HDMI 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 2 |
| SERIAL PORT | COM1~2 (RS232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS/eDP x 1(Default: LVDS) Inverter x 1 (12V/2A) |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio function not available for WiTAS SKU |
| DIO/GPIO | GPIO 8-bit |
| SMBus/I2C | SMBus/ I2C x 1 (Default: SMBus) |
| FAN | 4pins Smart Fan x1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| MINI PCI-E/MSATA | Half Size mSATA/mPCIe x 1 (default: mSATA, select with BIOS) |
| M.2 | M.2 2280 M-Key x 1 (PCIe 4.0 [x4]) |
| Others | MIPI-CSI via 61-Pin FPC Connector |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | 32°F ~ 140°F (0°C ~ 60°C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 1,087,053 |
| EMC | CE/FCC Class A |
