| SYSTEM | |
| FORM FACTOR | Pico-ITX |
| CPU | Intel® 11th Generation Core™ i3-1115G4E (2C/4T, 2.20GHz, 15W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | Onboard LPDDR4x 3200, Dual Channel, In-Band ECC, 4GB |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 3.94" x 2.84" (100mm x 72mm) |
| Gross Weight | 0.18 lbs. (0.08 kg) |
| OS Support | Windows 10 (64bit) Linux Ubuntu 20.10.2/Kernel 5.8.0-33-generic |
| POWER | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | AT/ATX |
| CONNECTOR | Phoenix 2-pin Connector (Default) Lockable DC Jack Connector (colay) |
| POWER CONSUMPTION | Intel® i7-1185G7E, LPDDR4x onboard 32GB, 2.89A@ +12V (TYPICAL) |
| DISPLAY | |
| CONTROLLER | Intel® Iris® Xe (i5/i7 support) Intel® UHD Graphics (i3/Celeron support) |
| LVDS/eDP | eDP1.3 x 1, 3840 x 2160@60Hz |
| Display Interface | HDMI2.0 x 1, 3840 x 2160 @60Hz |
| Multiple Display | Up to 2 Simultaneous Displays |
| AUDIO | |
| CODEC | Realtek ALC269 (Optional) |
| AUDIO INTERFACE | — |
| EXTERNAL I/O | |
| ETHERNET | Intel® i225/226, 2.5GbE, RJ-45 x 1 Intel® i219, 1GbE, RJ-45 x 1 |
| USB | USB3.2 Gen 2 x 2 |
| VIDEO | HDMI2.0 x 1 |
| INTERNAL I/O | |
| USB | USB3.2 Gen 1 x 2 USB2.0 x 4 |
| SERIAL PORT | COM1, COM2 (RS232/422/485, supports 5V/12V/RI) |
| VIDEO | eDP x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | — |
| DIO/GPIO | 8-bit |
| SMBus/I2C | I2C/SMBus x1 (Default: SMBus) |
| FAN | 4 pins Smart Fan x1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| MINI PCI-E/MSATA | Full-Size mSATA/mPCIe x 1 (Default: mPCIe, select with BIOS) |
| M.2 | M.2 M Key 2280 x 1 (PCIe Gen 4 [x4] as default, SATA select by HW BOM ) |
| Others | SMBUS/I2C/eSPI x 1 |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | 32˚F ~ 140˚F (0˚C ~ 60˚C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 424,208 |
| EMC | CE,FCC Class A |
