| SYSTEM | |
| Form Factor | PICO-ITX |
| CPU | AMD RYZEN™ V2000 embedded Processor Family V2718 (8C/16T, 1.70GHz, 25W) |
| CHIPSET | Integrated with AMD RYZEN™ V2000 embedded Processor |
| Memory Type | Onboard LPDDR4x 3733, Dual Channel, Non-ECC, default with 32GB |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Levels |
| Security | TPM2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| Dimension (L x W) | 3.94" x 2.84" (100mm x 72mm) |
| Gross Weight | 0.18 lbs. (0.08 kg) |
| OS Support | Windows 10 (64 bit) Linux Ubuntu 20.04.3/Kernel 5.18.0-4449-amd+ |
| Power | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | AT/ATX |
| CONNECTOR | Phoenix 2-pin Connector (Default) Lockable DC Jack Connector (colay) |
| POWER CONSUMPTION | V2718, LPDDR4x 32GB, NVMe64GB 4.24A @ +12V(TYPICAL) V2718, LPDDR4x 32GB, NVMe64GB, 4.82A @ +12V(MAX) |
| Display | |
| CONTROLLER | AMD Radeon 6, 7 Graphics (Renoir) |
| LVDS/eDP | eDP1.3 x 1, 3840 x 2160 @60Hz |
| DISPLAY INTERFACE | Type C to DP x 1, 3480 x 2160 @60Hz HDMI 2.0 x 1, 3480 x 2160 @60Hz HDMI 1.4 x 1, 3480 x 2160 @30Hz |
| MULTIPLE DISPLAY | Up to 4 Simultaneous Displays |
| Audio | |
| CODEC | Realtek ALC269 (Optional) |
| AUDIO INTERFACE | audio function not available for WiTAS SKU |
| EXTERNAL I/O | |
| ETHERNET | Intel® i225/i226 2.5GbE, RJ-45 x 1 Intel® i210 1GbE, RJ-45 x 1 |
| USB | USB3.2 Gen2 Type C x 1 USB3.2 Gen2 x 2 |
| SERIAL PORT | — |
| VIDEO | DP x 1 (Via Type C) HDMI 2.0 x 1 HDMI 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB2.0 x 4 |
| SERIAL PORT | COM1~4 (RS232/422/485, support 5V/12V/RI) |
| VIDEO | eDP x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | audio function not available for WiTAS SKU |
| DIO/GPIO | GPIO 8-bit |
| SMBUS/I2C | SMBus x 1 |
| FAN | 4 pins Smart Fan x1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| MINI PCI-E/MSATA | Full-Size mSATA/mPCIe x 1 (Default: mPCIe, select with HW BOM) |
| M.2 | M.2 2280 M-Key x 1 (PCIe 4.0 [x4]/SATA, Default: PCIe [x4], select with BIOS) |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | WiTAS 2 -40°F ~ 185°F (-40°C ~ 85°C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 407,784 |
| EMC | CE/FCC Class A |
