Thông Số Kỹ Thuật Tên gọi Asrock Z370 EXTREME4 CPU hỗ trợ Intel® Socket 1151 for 8th Generation Core™ Processors Chipset / Socket Intel® Z370 Bộ nhớ (RAM) • 4 x DIMM, Max. 64GB, DDR4 • Dual Channel Memory Architecture • Supports Intel® Extreme Memory Profile (XMP) Công nghệ đa GPU • Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies • Support for AMD Quad-GPU CrossFireX™ and 3-Way/2-Way AMD CrossFire™ technologies Khe cắm mở rộng • 3 x PCI Express 3.0 x16 Slots • 3 x PCI Express 3.0 x1 Slots • Supports NVIDIA® Quad SLI™ and SLI™ • 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module LAN • Intel® I219V Âm thanh • Realtek ALC1220 Audio Codec Cổng kết nối (Internal) • 1 x COM Port Header • 1 x TPM Header • 1 x Power LED and Speaker Header • 1 x RGB LED Header* • 1 x CPU Fan Connector (4-pin) • 1 x CPU Optional/Water Pump Fan Connector (4-pin) • 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) • 1 x Chassis Optional/Water Pump Fan Connector (4-pin) • 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) • 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) • 1 x Front Panel Audio Connector (15μ Gold Audio Connector) • 1 x Thunderbolt™ AIC Connector (5-pin) • 3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Intel® Z370) (Supports ESD Protection) • 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Intel® Z370) (Supports ESD Protection) • 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection) • 1 x Front Panel Type C USB 3.1 Gen1 Header (ASMedia ASM1074 hub) Cổng kết nối (Back Panel) • 2 x Antenna Ports • 1 x PS/2 Mouse/Keyboard Port • 1 x D-Sub Port • 1 x DVI-D Port • 1 x HDMI Port • 1 x Optical SPDIF Out Port • 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM3142) (Supports ESD Protection) • 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM3142) (Supports ESD Protection) • 4 x USB 3.1 Gen1 Ports (Intel® Z370) (Supports ESD Protection) • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) • HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Công nghệ độc quyền • ASRock USB 3.1 Gen2 - ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s) • ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 60A Power Choke - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) - Dual-Stack MOSFET (DSM) - Combo Caps (Nichicon 12K Black Caps) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB • ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology • ASRock Steel Slots • ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) • ASRock Full Spike Protection (for all USB, Audio, LAN Ports) • ASRock Live Update & APP Shop Phụ kiện đi kèm • Quick Installation Guide, Support CD, I/O Shield • 4 x SATA Data Cables • 1 x ASRock SLI_HB_Bridge_2S Card • 3 x Screws for M.2 Sockets Hệ điều hành khuyến nghị • Windows® 10 64-bit Chuẩn kích cỡ • ATX Form Factor | |
