Mainboard Msi B360m Pro-vdh Socket Lga1151v2 _1118kt

Thông Số Kỹ Thuật
PROCESSOR
Supports 9th/ 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
See supported processors
CHIPSET
Intel® B365 Chipset
MEMORY
•           4 x DDR4 memory slots, support up to 64GB
•           Supports DDR4 2666/ 2400/ 2133 MHz
•          Supports Dual-Channel mode
•           Supports non-ECC, un-buffered memory
•           Supports Intel® Extreme Memory Profile (XMP)
See supported memory
SLOTS
•           1 x PCIe 3.0 x16 slot
•           2 x PCIe 3.0 x1 slots
ONBOARD GRAPHICS
•           1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
STORAGE
Intel® B365 Chipset
•           6 x SATA 6Gb/s ports1
•           1 x M.2 slots (Key M)
o          Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
o          Intel® Optane™ Memory Ready2
1.         SATA1 port will be unavailable when installing SATA M.2 SSD in M.2 slot.
2.         Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
USB
Intel® B365 Chipset
•           6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
•           6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
AUDIO
Realtek® ALC892 Codec
•           7.1-Channel High Definition Audio
LAN
•           1 x Intel® I219-V Gigabit LAN controller
INTERNAL CONNECTORS
•           1 x 24-pin ATX main power connector
•           1 x 8-pin ATX 12V power connector
•           6 x SATA 6Gb/s connectors
•           1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
•           2 x USB 2.0 connectors (support additional 4 USB 2.0 ports)
•           1 x 4-pin CPU fan connector
•           2 x 4-pin system fan connectors
•           1 x Front panel audio connector
•           2 x Front panel connectors
•           1 x Serial port connector
•           1 x Parallel port connector
•           1 x 3-pin RAINBOW LED connector
•           1 x 4-pin RGB LED connector
•           1 x TPM module connector
•           1 x Chassis Intrusion connector
•           1 x Clear CMOS jumper
BACK PANEL PORTS
1.         Mouse Port
2.         Intel GAMING LAN
3.         HD Audio Connectors
4.         Keyboard Port
5.         USB 2.0 ports
6.         HDMI Port
7.         USB 3.1 Gen1 Type-A ports
8.         USB 3.1 Gen1 Type-A+C ports
DIMENSIONS
•           9.6 in. x 9.6 in. (24.3 cm x 24.3 cm)
•           Micro-ATX Form Factor
MOUNTING
8 mounting holes
OPERATING SYSTEM
•           Support for Windows® 10 64-bit
