| SYSTEM | |
| CPU | Intel® Celeron N3350 processor |
| CHIPSET | Intel® System on Chip |
| SYSTEM MEMORY | (Default: No) DDR3L 1866, Single Channel SODIMM x 1, Non-ECC (Max.8GB, up to 1600MHz) |
| DISPLAY INTERFACE | HDMI (max. 1920 x 1080) |
| STORAGE DEVICE | mSATA |
| ETHERNET | Intel i211-AT x 2 |
| I/O | Power Button x 1 |
| EXPANSION | Full-size Mini PCIe slot x 1 (PCIe/USB/SIM slot), one screw Half-size Minicard slot x 1 (mSATA only) |
| INDICATOR | Power LED x1, HDD active LED x1 |
| OS SUPPORT | Windows® 10, Windows® 10 IoT, Linux |
| POWER SUPPLY | |
| POWER REQUIREMENT | 9~24V with 3-pin terminal block |
| MECHANICAL | |
| MOUNTING | Wallmount |
| DIMENSIONS (W X H X D) | 6.54" x 4.2" x 1.45" (166mm x 106.6mm x 37mm) |
| GROSS WEIGHT | 3.6 lb (1.6kg) |
| NET WEIGHT | 1.76 lb (0.8 kg) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~ 140°F (-20°C ~ 60°C) with W.T. mSATA (according to IEC68-2-14 with 0.5 m/s AirFlow; with industrial devices) |
| STORAGE TEMPERATURE | -22°F ~ 140°F (-30°C ~ 60°C) |
| STORAGE HUMIDITY | 95% @ 40°C, non-condensing |
| ANTI-VIBRATION | 3 Grms/ 5 ~ 500Hz/ operation – mSATA 1 Grms /5 ~ 500Hz/ operation - HDD |
| CERTIFICATION | CE/FCC class A |
