| SYSTEM | |
| CPU | Intel® Processor N50 (formerly Alder Lake-N) |
| CHIPSET | Intel® SoC |
| SYSTEM MEMORY | (Default: No) DDR5 4800Mhz SODIMM x 1, up to 32GB |
| DISPLAY INTERFACE | HDMI x 2 |
| STORAGE DEVICE | M.2 2280 M-Key x 1 (PCIe Gen 3 x 2) 2.5" SATA HDD/SSD x 1 |
| ETHERNET | RJ-45 x 2 for 2.5GbE LAN (Intel® I226-LM) |
| I/O | HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® I226-LM) USB 3.2 Gen 2 x 2 (Type-A) USB 2.0 x 2 (Type-A) DB-9 x 3 for RS-232/422/485 DB-15 x 1 Male for Digital I/O 8-Channel 3-pin Terminal Block for DC In x 1 Power Button with LED x 1 |
| EXPANSION | M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 Full-Size Mini Card x 1 (PCIe + USB) SIM Slot x 1 |
| INDICATOR | — |
| OS SUPPORT | Windows® 10 IoT Enterprise Windows® 11 Pro Linux Ubuntu 22.04 |
| POWER SUPPLY | |
| POWER REQUIREMENT | 9 ~ 36V DC-In x 1 for 3-pin Terminal Block |
| MECHANICAL | |
| MOUNTING | Wallmount |
| DIMENSIONS (W X H X D) | 7.32" x 4.12" x 1.93" (186mm x 104.6mm x 49.1mm) without bracket 8.74" x 4.12" x 2.21" (222mm x 104.6mm x 56.1mm) with bracket |
| GROSS WEIGHT | 4.32 lb (1.96 Kg) |
| NET WEIGHT | 2.56 lb (1.16 Kg) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~ 140°F (-20°C ~ 60°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) |
| STORAGE TEMPERATURE | -40°F ~ 176°F (-40°C ~ 80°C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40°C, non-condensing |
| ANTI-VIBRATION | 3 Grms/ 5 ~ 500Hz/ operation (with SSD) |
| ANTI-SHOCK | 50G, IEC 68-2-27, half sine, 11 ms duration (with SSD) |
| CERTIFICATION | CE/FCC Class A |
