| SYSTEM | |
| CPU | Intel® Core™ i7-1265UE |
| CHIPSET | Intel® SoC |
| SYSTEM MEMORY | DDR4 SODIMM x1 (Maximum support: up to 32GB) |
| DISPLAY INTERFACE | HDMI 1.4b x 2 (Type-A) |
| STORAGE DEVICE | 2.5” SATA-III Drive Bay x1 M.2 2280 M Key x1 (PCIEx4) |
| ETHERNET | RJ-45 x 1 for 2.5GbE (Intel® I226-LM) RJ-45 x 1 for GbE (Intel® I219-LM) |
| I/O | USB 3.2 Gen 2 x 3 (Type-A) |
| EXPANSION | M.2 2230 E-Key x 1 (Wi-Fi/BT) M.2 3052 B-Key w/ SIM x 1 (LTE/5G) M.2 2280 M-Key x 1 (NVMe) |
| INDICATOR | Power Button with LED |
| OS SUPPORT | Windows® 10 IoT Ent LTSC Windows® 11 PRO Ubuntu 22.04 |
| POWER SUPPLY | |
| POWER REQUIREMENT | DC-in 12V x 1 for Lockable DC Jack |
| MECHANICAL | |
| MOUNTING | Wallmount |
| DIMENSIONS (W X H X D) | 7.68" x 4.37" x 2.5" (195mm x 111mm x 63.5mm) w/o bracket |
| GROSS WEIGHT | 4.4 lb (2Kg) |
| NET WEIGHT | 3.3 lb (1.5Kg) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~140°F (-20°C ~ 60°C), IEC68-2 with 0.5 m/s AirFlow with wide temperature Memory/Storage |
| STORAGE TEMPERATURE | -40˚F ~ 176˚F (-40˚C ~ 80˚C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40˚C, non-condensing |
| ANTI-VIBRATION | SSD: Random, 3Grms, 5~500Hz |
| ANTI-SHOCK | SSD: 50G @ wallmount, Half-sine, 11ms |
| CERTIFICATION | CE/FCC class A |
