| SYSTEM | |
| CPU | Intel® Celeron® N3350, 2.4 GHz |
| Chipset | Intel® System on Chip |
| System Memory | DDR3L 1866, Single Channel SODIMM x 1, Non-ECC (Max.8GB, up to 1600MHz) |
| Display Interface | HDMI (max. 2048 x 1152), VGA (max. 2048 x 1152) |
| Storage Device | mSATA, HDD/SSD |
| Ethernet | Intel® I211, 10/100/1000Base-TX x 2 |
| I/O | RS-232/422/485 x 2 RS-232 x 4 USB 3.2 Gen 1 x 4 VGA x 1 HDMI x 1 LAN x 2 Remote On/Off x 1 Reset Button x 1 AT/ATX DIP Switch Mic-In x 1 Line-Out x 1 Antenna holes x 1 Power button Power input |
| Expansion | Full-size Mini-Card x 1 (PCIE + USB, w/SIM slot) Half-size Mini-Card x 1 (mSATA + USB) |
| Indicator | Power LED HDD active LED |
| OS support | Windows® 10 IoT Ent LTSC 2019 64 bit Ubuntu 16.04 above |
| POWER SUPPLY | |
| Power Requirement | 9-24V with 3-pin terminal block |
| MECHANICAL | |
| Mounting | Wallmount DIN Rail (Mounting kit is optional) |
| Dimensions (W x H x D) | 197mm(W) x 55mm(H) x 110mm(D) |
| Gross Weight | 6.6 lb (2.8 kg) |
| Net Weight | 4.4 lb (2 kg) |
| ENVIRONMENTAL | |
| Operating Temperature | -4°F ~ 158°F (-20°C ~ 70°C) with W.T. SSD/HDD/mSATA (according to IEC682-14 with 0.5 m/s AirFlow; with industrial devices) |
| Storage Temperature | -4°F ~ 158°F (-20°C ~ 70°C) |
| Storage Humidity | 95% @ 40°C, non-condensing |
| Anti-Vibration | 3 Grms/ 5 ~ 500Hz/ operation – mSATA/SSD 1 Grms/ 5~ 500Hz/ operation – HDD |
| Certification | CE/FCC class A |
