| SYSTEM | |
| CPU | Intel Atom® x7211E |
| CHIPSET | Intel® SoC |
| SYSTEM MEMORY | — |
| SYSTEM MEMORY | DDR5 4800 MT/s SO-DIMM slot x 1, up to 32GB |
| DISPLAY INTERFACE | HDMI x 2 |
| STORAGE DEVICE | M.2 2280 M-Key x 1 (PCIe [x2]) 2.5” SATA HDD/SSD x 1 |
| ETHERNET | RJ-45 x 2 for 2.5GbE LAN (Intel® I226) |
| I/O | HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® I226) USB 3.2 Gen 2 (Type-A) x 2 USB 2.0 (Type-A) x 2 DB-9 x 3 for RS-232/422/485 DB-15 x 1 for 8-bit DIO 3-pin Terminal Block for DC in x 1 Power Button with LED x 1 |
| EXPANSION | M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 Full Size Mini Card x1 (PCIe + USB) SIM Slot x 1 |
| INDICATOR | — |
| OS SUPPORT | Windows® 10 IoT Enterprise Windows® 11 Pro Linux Ubuntu 22.04 |
| POWER SUPPLY | |
| POWER REQUIREMENT | DC-in 9-36V x1 for 3-pin Terminal Block |
| MECHANICAL | |
| MOUNTING | DIN Rail Mount |
| DIMENSIONS (W X H X D) | 1.89" x 7.48" x 4.88" (48mm x 190mm x 124mm) |
| GROSS WEIGHT | 3.50 lb (1.59 Kg) |
| NET WEIGHT | 2.40 lb (1.09 Kg) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~ 140°F (-20°C ~ 60°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) |
| STORAGE TEMPERATURE | -40˚F ~ 176˚F (-40˚C ~ 80˚C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40˚C, non-condensing |
| ANTI-VIBRATION | 3 Grms/ 5 ~ 500Hz/ operation (with SSD) |
| CERTIFICATION | CE/FCC class A |
