| SYSTEM | |
| CPU | Intel® Core™ i7-1265UE |
| CHIPSET | Intel® SoC |
| RAM | — |
| SYSTEM MEMORY | DDR4 SODIMM x 1, up to 32GB |
| DISPLAY INTERFACE | HDMI 1.4b (Type-A) x 2 |
| STORAGE DEVICE | 2.5” SATA III Drive Bay x 1 M.2 2280 M-Key x 1 (PCIe [x4]) |
| ETHERNET | RJ-45 x 1 for Intel® I226-LM, 2.5GbE RJ-45 x 1 for Intel® I219-LM, GbE |
| I/O | USB 3.2 Gen 2 (Type-A) x 3 USB 2.0 (Type-A) x 3 DB-9 x 2 for RS-232/422/485 DB-15 x 1 for DIO 8-bit HDMI 1.4b (Type-A) x 2 Audio x 1 for Line-Out Power Button x 1 3-pin Terminal Block for DC-in x 1 Antenna Opening x 4 |
| EXPANSION | M.2 2230 E-Key x 1 (Wi-Fi/BT) M.2 3052 B-Key w/ SIM x 1 (LTE/5G) M.2 2280 M-Key x 1 (NVMe) |
| INDICATOR | Power Button with LED |
| OS SUPPORT | Windows® 10 IoT Ent LTSC Windows® 11 PRO Ubuntu 22.04 |
| POWER SUPPLY | |
| POWER REQUIREMENT | DC 9 - 36V with 3-pin terminal block |
| MECHANICAL | |
| MOUNTING | DIN Rail Mount Wallmount (Mounting kit is optional) |
| DIMENSIONS (W X H X D) | 2.93” x 7.32” x 5.0” (74.3mm x 186mm x 127mm) |
| GROSS WEIGHT | 5.3 lb (2.41 Kg) |
| NET WEIGHT | 3.9 lb (1.77 Kg) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~140°F (-20°C ~ 60°C), IEC68-2 with 0.5 m/s AirFlow |
| STORAGE TEMPERATURE | -40˚F ~ 176˚F (-40˚C ~ 80˚C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40˚C, non-condensing |
| ANTI-VIBRATION | With SSD: Random, 3 Grms, 5~500Hz |
| CERTIFICATION | CE/FCC class A |
