| SYSTEM | |
| FORM FACTOR | PICO-SEMI |
| CPU | Intel® Celeron® Processor N6210 (2C/2T, 1.20 GHz, 6.5W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | Onboard Single-Channel LPDDR4x 3200MHz (Default with 4GB, Max. 16GB, Non ECC) |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | Intel® PTT (Integrated TPM) |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 4.80" x 3.18" x 1.75" (122mm x 80.8mm x 44.4mm) |
| Gross Weight | 0.88 lb. (0.40kg) |
| OS Support | Windows 10 (64 bit) Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| POWER REQUIREMENT | 12V only |
| POWER SUPPLY TYPE | ATX |
| CONNECTOR | DC Jack Connector |
| POWER CONSUMPTION | Intel® Pentium® J6426, LPDDR4x onboard 16GB, 1.43A@ +12V(TYPICAL) Intel® Pentium® J6426, LPDDR4x onboard 16GB, 1.78A@ +12V(MAX) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| Display Interface | HDMI 2.0 x 1, 3840 x 2160 @60Hz |
| Multiple Display | Up to 1 Display |
| EXTERNAL I/O | |
| ETHERNET | RTL8111H-CG 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| SERIAL PORT | COM 1, COM 2 (RS-232/422/485, supports 5V/12V/RI, Optional) |
| VIDEO | HDMI 2.0 x 1 |
| INTERNAL I/O | |
| SATA | 32GB eMMC 5.1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full size mPCIe/mSATA x 1 (SATA as default, PCIe selected by BIOS) |
| M.2 | M.2 2230 E-Key x 1 (PCIe [x1]/USB 2.0) |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | 32°F ~ 122°F (0°C ~ 50°C) with 0.5m/s air flow |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 489,989 |
| EMC | CE/FCC Class A |
