| SYSTEM | |
| FORM FACTOR | PICO-SEMI |
| CPU | Intel® 11th Generation Core™ Processors: i5-1145G7E (4C/8T, 1.5GHz, 15W) |
| CHIPSET | Integrated with Intel® SoC |
| MEMORY TYPE | Onboard LPDDR4x 3200, Dual Channel, In-Band ECC (select SKUs, Default: 8GB) |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | TPM2.0 (Optional) |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 4.80" x 3.18" x 1.98" (122mm x 80.8mm x 50.4 mm) |
| Gross Weight | 0.84 lbs (0.38 kg) |
| OS Support | Windows 10 (64bit) Linux Ubuntu 20.10.2/Kernel 5.8.0-33-generic |
| POWER | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | ATX |
| CONNECTOR | DC Jack Connector |
| POWER CONSUMPTION | Intel® i7-1185G7E, LPDDR4x 32GB, 2.89A@ +12V (TYPICAL) |
| DISPLAY | |
| CONTROLLER | Intel® Iris® Xe |
| LVDS/eDP | — |
| Display Interface | HDMI2.0 x 1, 3840 x 2160 @60Hz |
| Multiple Display | Single display |
| AUDIO | |
| CODEC | Realtek ALC269 (By request) |
| AUDIO INTERFACE | Line-out (By request) |
| EXTERNAL I/O | |
| ETHERNET | Intel® i225/226, 2.5GbE, RJ-45 x 1 Intel® i219, 1GbE, RJ-45 x 1 |
| USB | USB3.2 Gen2 x 2 |
| SERIAL PORT | COM1~2 (RS232/422/485, support 5V/12V/RI, Optional) |
| VIDEO | HDMI2.0 x 1 |
| INTERNAL I/O | |
| AUDIO | Line-out (By request) |
| FAN | 4pins Smart Fan x 1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full-Size mSATA/mPCIe x 1 (Default: mPCIe, select with BIOS) |
| M.2 | M.2 2280 M-Key x 1 (PCIe 4.0 [x4]/SATA, Default: PCIe [x4], select with HW BOM) |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMP | 32°F ~ 122°F (0°C ~ 50°C) |
| STORAGE TEMP | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 424,208 |
| EMC | CE/FCC Class A |
