| SYSTEM | |
| FORM FACTOR | PICO-SEMI |
| CPU | AMD RYZEN™ V2000 embedded Processor Family V2516 (6C/12T, 2.10GHz, 25W) |
| CHIPSET | Integrated with AMD RYZEN™ V2000 embedded Processor |
| MEMORY TYPE | Onboard LPDDR4x 3733, Dual Channel, Non-ECC, default with 8GB |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | TPM2.0 |
| RTC Battery | Lithium Battery 3V/240mAh |
| DIMENSION | 4.80” x 3.18” x 2.13” (122mm x 80.8mm x 54 mm) |
| Gross Weight | 0.84 lbs. (0.38 kg) |
| OS Support | Windows 10 (64 bit) Linux Ubuntu 20.04.3/Kernel 5.18.0-4449-amd+ |
| POWER | |
| POWER REQUIREMENT | +12V |
| POWER SUPPLY TYPE | ATX |
| CONNECTOR | DC Jack Connector |
| POWER CONSUMPTION | V2718, LPDDR4x 32GB, NVMe64GB 4.24A @ +12V(TYPICAL) V2718, LPDDR4x 32GB, NVMe64GB, 4.82A @ +12V(MAX) |
| DISPLAY | |
| CONTROLLER | AMD Radeon 6, 7 Graphics (Renoir) |
| Display Interface | Type C to DP x 1, 3480 x 2160 @60Hz HDMI 2.0 x 1, 3480 x 2160 @60Hz HDMI 1.4 x 1, 3480 x 2160 @30Hz |
| Multiple Display | Up to 3 Simultaneous Displays |
| AUDIO | |
| CODEC | Realtek ALC269 (Optional) |
| AUDIO INTERFACE | Line-out (Optional) |
| EXTERNAL I/O | |
| ETHERNET | Intel® i225/i226 2.5GbE, RJ-45 x 1 Intel® i210 1GbE, RJ-45 x 1 |
| USB | USB3.2 Gen2 Type C x 1 USB3.2 Gen2 x 2 USB2.0 x 2 (Optional) |
| SERIAL PORT | COM1~2 (RS232/422/485, support 5V/12V/RI, Optional) |
| VIDEO | DP x 1 (Via Type C) HDMI 2.0 x 1 HDMI 1.4 x 1 |
| INTERNAL I/O | |
| SATA | Onboard NVME SSD 64GB |
| AUDIO | Line-out (Optional) |
| FAN | 4pins Smart Fan x1 |
| Front Panel | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full-Size mSATA/mPCIe x 1 (Default: mPCIe, select with HW BOM) |
| M.2 | M.2 2280 M-Key x 1 (PCIe 4.0 [x4]/SATA, Default: PCIe [x4], select with BIOS) |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | 32°F ~ 122°F (0°C ~ 50°C) with 0.2 m/s airflow |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| OPERATING HUMIDITY | 0% ~ 90% relative humidity, non-condensing |
| MTBF (HOURS) | 407,784 |
| EMC | CE/FCC Class A |
