| SYSTEM | |
| CPU | Intel® Core™ i3-N305 (8C, 1.80 GHz, 15W) Onboard Hailo-8™ edge AI processor |
| Memory | 16GB onboard LPDDR5 |
| Graphics | Intel® UHD Graphics for 12th Gen Intel® Processors |
| Storage | 128GB onboard eMMC |
| Ethernet | 2.5GbE x 2 (Intel® I226-IT) |
| WIFI/BT | Optional with M.2 2230 E-key x 1 |
| Expansion Slot | M.2 2230 E-Key x 1 (CNVI, PCIe Gen 3 [x1], USB 2.0) M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]), Optional: M.2 3052 B-Key with Nano SIM slot (USB 3.0) |
| Security | Onboard TPM 2.0 |
| OS Support | Windows® 10 IoT Enterprise Ubuntu 22.04 LTS |
| I/O Placements | |
| USB | USB 3.2 Gen 2 x 2 (Type-A) |
| Display Port | HDMI 2.0b x 1 DP 1.2 x 1 |
| Ethernet | 2.5GbE x 2 (Intel® I226-IT) |
| COM | RS-232/422/485 x 2 |
| Audio | — |
| GPIO | 40-pin GPIO x 1 |
| POWER Supply | |
| Power requirement | 12V-36V DC-in Phoenix connector (Optional: Lockable plug) |
| Power Supply Type | AT/ATX (AT as default) |
| Power Consumption (Typical) | 50W~55W |
| Mechanical | |
| Mounting | VESA Mount/Wall Mount/DIN RAIL (Optional) |
| Dimensions (WxHxD) | 5.28" x 4.13" x 2.36" (134mm x 105mm x 60mm) |
| Net Weight | 1.8 lbs (0.69kg) |
| Gross Weight | 2.2 lbs (0.97kg) |
| Environment | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) / 0.5 airflow |
| Operation Humidity | 0% ~ 90% relative humidity, non-condensing |
| Storage Temperature | -4°F ~ 158°F (-20°C ~ 70°C) |
| MTBF | 422,053 Hours |
| Certification | CE/FCC Class A, RoHS Compliant, REACH |
