| SYSTEM | |
| Processor | Intel® Core™ i3-N305 |
| Graphics | Intel® UHD Graphics for 12th Gen Intel® Processors |
| Memory | 16GB LPDDR5 |
| Storage | 64GB onboard eMMC |
| Ethernet | 2.5GbE x 2 (Intel® I226-IT) |
| WIFI/BT | Optional with M.2 2230 E-key x 1 |
| Expansion Slot | M.2 3052 B-Key x 1 with Nano SIM slot (USB 3.0) M.2 2230 E-Key x 1 (USB 2.0/PCIe) M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]) 24V 8-in/8-out Digital I/O x 1 via Terminal Block (Output current: 500mA per channel) 6 pin 2-channel CAN 2.0B x 1 via Terminal Block (10 ~ 1000 kbps) DIP Switch for CANBus function x 1 CAN LED indicator x 2 SATA III x 1 |
| Security | Onboard TPM 2.0 |
| OS Support | Ubuntu 22.04 LTS (Kernel 5.15 and kernel 5.19) |
| I/O Placements | |
| USB | USB 2.0 (Type-A) x 2 USB 3.2 (Type-A) x 2 USB 3.2 Gen 2 (Type-C) x 1 (Supports DP alt mode) |
| Display Port | DP 1.4a x 1 (via USB Type-C) |
| Ethernet | RJ45 x 2 |
| COM | RS-232/422/485 x 1 (Terminal Block) (Default RS232) |
| Audio | — |
| GPIO | 6 pin GPIO x 1 via Terminal Block |
| POWER Supply | |
| Power requirement | 9-36V |
| Power Supply Type | AT/ATX (AT as default) |
| Power Consumption (Typical) | 52W~55W |
| Mechanical | |
| Mounting | 75mm x 75mm VESA mount, optional Wall mount kit |
| Dimensions (WxHxD) | 5.98” x 4.8” x 1.7” (152mm x 124mm x 40mm) |
| Net Weight | 2.21lb (1.0Kg) |
| Gross Weight | 3.31lb (1.5Kg) |
| Environment | |
| Operating Temperature | 32°F ~ 131°F (0°C ~ 55°C)/0.5m/s airflow |
| Operation Humidity | 0% ~ 90% relative humidity, non-condensing |
| Storage Temperature | -4°F ~ 158°F (-20°C ~ 70°C) |
| MTBF | 421,998 |
| Certification | CE/FCC Class A, RoHS Compliant, REACH |
