| SYSTEM | |
| FORM FACTOR | Multi-PoE & Fanless Appliance |
| PROCESSOR | Intel® Atom™ x5-E3940 Processor |
| Main Memory | DDR3L 1866, Single Channel SODIMM x 1, Non-ECC (Max.8GB, up to 1600MHz) |
| Display | HDMI x 1, DP x 1 |
| ETHERNET | Intel® i211 (colay i210) |
| POE ETHERNET PORT | 4 ports, sharing 60W of power budget for every four PoE ports |
| RAID SUPPORT | — |
| EXPANSION SLOT | Mini-Card slot x 2 (USB2.0 + PCIe, full size) SATA x 1 |
| FRONT I/O PANEL | Power Button x 1 Reset Button x 1 Power/HDD LED x 2 USB 3.2 Gen 1 x 2 GbE port (RJ-45) x 1 PoE LAN x 4 (IEEE 802.3 at/af) HDMI x 1 |
| REAR I/O PANEL | DC-In power x 1 8-bit DIO x 1, 4-ch digital input, 4-ch digital output RS-232/422/485 x 2 DP x 1 Audio Line-out x 1 Mic-In x 1 Micro SIM slot x 2 |
| STORAGE | |
| HDD | 2.5” HDD/SSD Bay x 1 |
| CF/CFAST/MSATA | — |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~ 158°F (-20°C ~ 70°C) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| STORAGE HUMIDITY | 10%~80% @40°C, non-condensing |
| VIBRATION/SHOCK | MIL-STD-810G |
| CERTIFICATION | CE & FCC Class A |
| POWER REQUIREMENT | |
| POWER SUPPLY | DC 12-24V |
| MECHANICAL | |
| INTERNAL SYSTEM HDD BAY | — |
| DIMENSION | 6.3" x 5.28" x 2.44" (160mm x 134mm x 62mm) |
| GROSS WEIGHT | 3.96 lb (1.8 kg) |
