| SYSTEM | |
| Form Factor | Multi-PoE & Fanless Appliance |
| Processor | Intel® 7th Gen. Core™ i3-7100U Processor |
| Chipset | — |
| Main Memory | Up to 32GB, DDR4 260-pin SODIMM |
| Display | HDMI x 1, DP x 1 |
| Ethernet | LAN x 2 + 4 PoE Ports, RTL8111E 10/100/1000 Base |
| PoE Ethernet Port | 4 ports, sharing 60W of power budget for every four PoE ports |
| RAID Support | 0/1 |
| Expansion Slot | Mini-Card slot x 3 (USB2.0 x 2 + PCIe & USB 2.0 x 1) Built-in CAN 2.0B x 1 |
| GPS | On board (GPS/GLONASS), G Sensor |
| Front I/O Panel | Power Button x 1 3G/4G/WIFI LED x 3 USB 3.2 Gen 1 x 4 GbE port (RJ-45) x 2 PoE LAN x 4 (IEEE 802.3 at/af) DP x 1 Reset Button x 1 |
| Rear I/O Panel | DC-In power x 1 Remote Power x 1 8bit DIO x 1, 4-ch digital input (Wet/dry contact with Isolation Protection 3,000 VDC) , 4-ch digital output (Compatible 5 V/TTL, 31 mA max. per channel) DC 12V/1A Output x 1 RS-232/422/485 x 2 HDMI x 1 CanBus connector x 1, Audio Line-out x 1, Mic-In x 1 SIM slot x 2 |
| STORAGE | |
| HDD Tray | 2.5” SSD x 2 |
| CF/CFast/mSATA | mSATA Slot x 1 (Optional, if mSATA x 1 used, then only one SATA available) |
| ENVIRONMENTAL | |
| Operating Temperature | -4°F ~ 158°F (-20°C ~ 70°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Storage Humidity | 10%~80% @40°C, non-condensing |
| Vibration/Shock | MIL-STD-810G |
| Certification | CE & FCC Class A, EMARK |
| POWER REQUIREMENT | |
| Power Supply | DC 10-36V, with ignition pin |
| MECHANICAL | |
| Internal System HDD Bay | 2.5" HDD x 2 |
| Dimension | 6.85” x 7.87” x 2.52” (174mm x 200mm x 64mm) |
| Gross Weight | 5.7 lb (2.6 kg) |
