| SYSTEM | |
| FORM FACTOR | Multi-PoE & Fanless Appliance |
| PROCESSOR | 12th Generation Intel® Core™ i7-1265UE Processor |
| Main Memory | DDR5 SODIMM x 2, up to 64GB |
| Display | HDMI x 2 |
| ETHERNET | 2.5GbE x 1 (Intel® I226-LM) |
| SMART POE | 2.5GbE x 4 (IEEE802.3 at/af, sharing 60W of power budget for every four PoE ports) |
| RAID SUPPORT | — |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe [x1] + USB 2.0, for WiFi/Bluetooth Module) M.2 3052 B-Key w/ Dual-SIM x 2 (USB 3.0 + USB 2.0, for LTE/5G Module) M.2 2280 M-Key x 1 (PCIe [x4]), support NVME PCIe [x4] SSD) |
| FRONT I/O PANEL | USB 3.2 Gen 2 (Type-A) x 2 USB 2.0 (Type-A) x 2 2.5GbE LAN x 1 2.5GbE PoE LAN x 4 (IEEE802.3 at/af) Jack x 1 for Line-out & MIC-in Reset Button x 1 Power Button x 1 |
| REAR I/O PANEL | DB-9 Male x 2 for RS-232/422/485 DB-9 Male x 1 for Isolated CANBus FD x 2 DB-15 Male x 1 for DIO 8 bit HDMI 1.4b x 2 3-pin Terminal Block x 1 DIP Switch x 1 SIM Slot x 4 |
| STORAGE | |
| HDD | 2.5” HDD/SSD Bay x 1 |
| CF/CFAST/MSATA | — |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -40°F ~ 158°F (-40°C ~ 70°C), IEC68-2 with 0.5 m/s AirFlow |
| STORAGE TEMPERATURE | -40˚F ~ 176˚F (-40˚C ~ 80˚C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40˚C, non-condensing |
| VIBRATION/SHOCK | MIL-STD-810H |
| CERTIFICATION | CE/FCC Class A, UKCA, E-Mark |
| POWER REQUIREMENT | |
| POWER SUPPLY | DC-in 9~36V x 1 for 3-pin Terminal Block |
| MECHANICAL | |
| INTERNAL SYSTEM HDD BAY | 2.5” HDD/SSD Bay x 1 |
| DIMENSION | 9.45" x 6.58" x 2.99" (240mm x 167.1mm x 76mm) Without brackets 11.69" x 6.58" x 3.27" (297mm x 167.1mm x 83mm) With brackets |
| GROSS WEIGHT | 7.93 lb (3.6 Kg) |
