Total # Of Inputs | 12-Mono Channels 2-Dedicated Stereo |
Mic/Line Inputs | 12 Mono Balanced XLR Microphone 2 Stereo L/R Balanced XLR Microphone 12 Mono Balanced 1/4" TRS Phone Line 2 Stereo L/R Balanced 1/4" TRS Phone Line |
Stereo Line Inputs | 2 Stereo L/R Balanced XLR Microphone 2 Stereo L/R Balanced 1/4" TRS Phone Line |
In-Line Inputs/Returns | No |
AUX Sends | 6-Total 4 Balanced XLR 2 Balanced 1/4" TRS Phone |
AUX Returns | 2 Stereo L/R 1/4" TRS Phone |
Inserts | 1/4" TRS Phone All Mono Inputs, Mix Output and Subgroup Outputs |
BUS (Group) Outputs | 2 Balanced XLR |
2 Trk Master I/O | Mix Output - 2 Balanced XLR Mono Output - 1 Balanced XLR |
ALT I/O | Direct Outputs (All Mono Channels) - 1/4" TRS Phone |
Monitor Outputs | Stereo L/R 1/4" TRS Phone |
EQ Section | Mono Input Channels: High pass Filter - 100Hz, 18dB/Octave HF - 13kHz, +/-15dB, 2nd order shelving Hi-Mid - 550Hz-13kHz, +/- 15dB, Q=1.5 Lo-Mid - 80Hz-1.9kHz, +/- 15dB, Q=1.5 LF - 80Hz, +/- 15dB, 2nd order shelving |
Solo/Mute | Mute, Mix, Subgroup and PFL on all channels |
Channel Level Control | 100mm Fader |
Trim/Gain Control | Rotary Controls |
Phantom Power | +48V |
Metering | Input Channels: Single LEDs, Signal Present & Peak Outputs: 2 tri-color, 12-segment LEDs |
Frequency Response | 20Hz to 20kHz < 1dB |
Dynamic Range | Not Specified By Manufacturer |
Signal-to-Noise Ratio | -128dBu, Measured RMS, 22Hz to 22kHz Bandwidth |
Total Harmonic Distortion (THD) | <0.006% |
Power Supply | Internal PSU: 90V-240V AC, 50/60Hz Universal Input Power Consumption: Less than 100W |
Dimensions (WxHxD) | 17.36 x 8.20 x 21.05" (441 x 208.42 x 534.79mm) |
Weight | Not Specified By Manufacturer |
